MR Block Board
KUTIRPLY MR Grade Blockboard is manufactured from the combianation of select hardwood and pinewood timber venners and adhesives. These are bonded with Melamine Formaldehyde Resin Under high pressure and temperature.
Technical Specification
| # | Test | Test Result | Value As Per ls-1659:2004 | |
|---|---|---|---|---|
| 1 | Dimension | |||
| a)Length | 2442mm | +6mm,-0 | ||
| b)Width | 1222 | +3mm,-0 | ||
| c)Thickness | 12.21mm | +5%,-5% | ||
| 2 | Squareness | 0.07% | Not more than 0.2% | |
| 3 | Edge Straightness | 0.05% | Not more than 0.2% | |
| 4 | Moisture Content | Excellent | Min.passed standard | |
| 5 | Adhesion of Piles | Excellent | Min.passed standard | |
| 6 | Resistance to Water | |||
| 7 | Static Bending Strength State |
| Modulus of Rupture | Modulus of Rupture | ||
|---|---|---|---|
| 41.16N/mm2 | |||
| 43.42 N/mm2 | Min 34 N/mm2 | ||
| 42.65 N/mm2 | Avg, 40 N/mm2 | ||
| Avg. 42.65 N/mm2 |
| Modulus of Rupture | Modulus of Rupture | ||
|---|---|---|---|
| 4166.15 N/mm2 | |||
| 4562.74 N/mm2 | Min 3400 N/mm2 | ||
| 4250.10 N/mm2 | Avg. 4000 N/mm2 | ||
| Avg. 4326.33 N/mm2 |
