ProductRange
Product range that paves way for innovation and creativity
Flush Door
Kutirply flush doors are manufactured from perfectly seasoned and chemically
treated solid wood construction with stiles and rails, Use of double layered
core veneer ensure smooth surface finish for decorative application
* 100% Bailing Water Proof (BWP) as Per IS 2202
* Processed On Advance Calibration Sanding Machine
* Structurally and Dimensionally Stable
* Decorative Teak Veneer Flush Door Available
Technical Specification
| # | Test | Result | As per Standard IS : 2202 |
|---|---|---|---|
| 1 | a)Dimension | Tolerance | |
| .Length | ±3mm | ±5mm | |
| .Width | ±3mm | ±5mm | |
| .Thickness | -0.5 to + 0.8mm | ±1mm | |
| .Squareness | 0.05% | Not more than 0.2% | |
| .Edge Straightness | 0.07% | Not more than 0.2% | |
| 2 | a)General Fitness Test | ||
| .Twist | 2.25mm | Not More Than 6mm | |
| .Cupping | 1.95mm | Not More Than 6mm | |
| .Warping | 2.31mm | Not More Than 6mm | |
| 3 | Local Planeness Test | 0.32mm | Not More Than 0.50mm |
| 4 | Impact Indentation Test | 0.15mm | No Defect and Depth of Indentation |
| Not More Than 0.20mm | |||
| 5 | Flexure Test | ||
| a. Residual Defection | 2.07mm* | Not More Than 1/10th of Max. | |
| Deflection | |||
| b. Maximum Defection | 41.05mm* | Not More Than 1/13th of Length. | |
| 6 | Edge Loading Test | ||
| a. Residual Defection | 0.21mm | Not More Than 0.50mm | |
| b.Maximum Defection | 3.31mm | Not More Than 5mm | |
| 7 | Shock Resistance Test | Satisfactory | No visible damage |
| 8 | Bucking Test | ||
| a.Residual Defection | 2.38mm | Not More Than 5mm | |
| b.Maximum Defection | 34.10mm | Not More Than 500mm | |
| 9 | Screw Withdeawal Test | 1400N | 1000N |
| 10 | Stamening Test | Satisfactory | No Visible Damage After 50 |
| Successive Impact | |||
| 11 | Misuse Test | Satisfactory | No Permanent Defocmation After |
| th Test | |||
| 12 | End Immersion Test | Satisfactory | No Defanatioin |
| 13 | Knife Test | Excellent | Min Pass Standard |
